Airway Procedures

Introduction

In this chapter we will heavily rely on information explored on Airway Ultrasound as it will be the basis for this chapter.  We will be making a recap on some key concepts.

Airway management is one of the most important and critical skills in the practice of Anesthesiology. Errors in this critical step of patient care is a major contributor to poor patient outcomes including brain hypoxia and death.

Ultrasound has a role in this critical aspect of care that can assist in clinical decision making. Ultrasound can identify the cricothyroid membrane for emergency airway access plus distinguish tracheal rings for ultrasound guided tracheostomy. Ultrasound can also be used to assist in airway blocks as we will see in this chapter.

Sensory Airway Innervation

The upper airway is divided into the nasal and oral cavities, the pharynx and larynx. Sensory innervation is provided by the trigeminal, glossopharyngeal and vagus nerves. As an alternative to and more challenging than topical anesthesia, three nerves can be blocked with the use of regional anesthesia for awake intubations and include the glossopharyngeal, superior laryngeal and the recurrent laryngeal block. The glossopharyngeal supplies sensory innervation to the posterior third of the tongue and vallecula and is not accessible with the use of ultrasound so will not be discussed here any further.

​

The superior laryngeal nerve provides sensation to the laryngeal structures above the vocal cords (posterior epiglotis, aryepiglottic folds and arytenoids ). It lies inferior to the greater cornu of the hyoid bone and then splits into the internal and external branches. The internal branch penetrates the thyrohyoid membrane continueing submucosally in the piriform recess. The external branch descends on the larynx. It is the internal branch of the superior laryngeal nerve that can be blocked with the use of ultrasound.

​

The recurrent laryngeal nerve provides innervation of the vocal cords and trachea and also provide motor supply to all intrinsic muscles of the larynx with the exception of the cricothyroid muscle. Blocking the recurrent laryngeal nerve will cause vocal cord paralysis and airway obstruction which is why this is not performed. A translaryngeal block achieves our goal of blocking only the sensory fibers of the nerve and is achieved by identifying the crycothyroid membrane. A 20 or 22 Gauge needle with syringe with local anesthesia is used and with continuous aspiration this membrane is perforated. Injection of local anesthesia (5ml of 4% lidocaine) and rapid withdrawal of the needle should follow. This results in coughing and helps disperse the solution to block the recurrent laryngeal nerve.

​

Conceptually we must first refresh ourselves with the bony anatomy of the larynx and its innervation which can be seen with the following illustrations. What we will be using on ultrasound is the location of these important bony structures to achieve appropriate targets.

​

​

Larynx unlabeled.jpg

 I

 E

R

​

Image by I8r8oosh

 I

 E

R

​

Natural Beauty

Anatomy of the larynx and relevant structures. On the left the anatomy of larynx and its innervation. On On the right, surface anatomy of the larynx and its innervation on frontal and side view.  Superior laryngeal nerve and its two branches, the internal (I) and external (E) laryngeal nerve. The recurrent laryngeal nerve can also be visualized (R). Image By Olek Remesz.

Equipment and Technique:

The evaluation of the upper airway involves an evaluation of the floor of the mouth and the neck and its associated structures. The floor of the mouth can be examined with a curvilinear probe (1-8MHz). The neck and its associated structures are better visualized with a linear high frequency probe (13-6Mhz).

Sonographic anatomy of the Airway, an Overview

Lets have a closer look at the corresponding images that we get with those scanning planes and later explore the clinical implications they have later in this chapter.

Floor of the mouth

Ultrasound images of the floor of the mouth. In these images, the floor of the mouth is explored in long and short axis. On the long axis view we appreciate the acoustic shadow caused by the mentum (M) and hyoid bones (H) with the probe moved  down the mouth and neck.

Image by I8r8oosh

1

2

M

H

Floor of the mouth in long (label 1) and short axis (label 2) planes. Images obtained with a curvilinear probe and less than 5 cm of sector depth. The hyperechoic line deep in the image corresponds to the air-tissue interface of the tongue.

US of the neck

1

2

Here the floor of the mouth is explored in long and short axis.  Bony structures create acoustic shadowing and thus limits the penetration of ultrasound waves into deeper tissues the hyperechoic line seen on these images corresponds to the air-tissue interface. We can use the following views to locate the cricothyroid membrane and the location of tracheal rings. If the esophagus lies directly posterior the trachea, is will not be visible on US.

Natural Beauty

1

2

01-2 neck lx down gif labels.gif

1

01-2 neck sx going down gif labels.gif

Thy

2

US of the neck in both the long axis or midline sagital plane (label 1) and short axis planes or transverse planes (label 2). The probe is moving down from the head to the base of the neck. T, thyroid cartilage; C, cricoid; S, tracheal rings creating the 'string of pearls' configuration', Thy, thyroid gland appears deeper in the neck as the probe is moved down. Images here obtained using a linear probe with less than 4cm of sector depth.

Sonographic anatomy of the Airway on Short Axis (Transv)

Lets have a closer look at what the different anatomical that you would see according to the interrogation planes along the short axis of the larynx. A diagram of the larynx and trachea is seen with slices taken at different levels as planes.  Their corresponding ultrasound images are seen.

1. Vocal cords

5.Trachea

Larynx unlabeled.jpg

  1

  2

  3

  4

  5

Anatomy of the larynx . Image By Olek Remesz

Section thyroid.gif

2. Thyroid cartilage

Section ct membrane.gif

3. Cricothyroid membrane

Section cricoid.gif

4.Cricoid cartilage

Sonographic anatomy of the Airway on Long Axis (Sagittal)

Lets have a closer look at what the different anatomical that you would see according to the interrogation planes along the long axis of the larynx. A diagram of the larynx and trachea is seen with a single slice corresponding to the movement of the ultrasound moving from head to the base of neck.

Larynx unlabeled_edited.jpg

Larynx viewed on long axis. The blue plane corresponds to the cut generated by the ultrasound beam. On the right we see the corresponding B mode clips while the ultrasound probe is moved in direction of the arrow above.   Larynx By Olek Remesz

Anatomical structures and clinical implications.

Ultrasound of the airway has various clinical implications improve airway management. Here our focus will be in the performance of regional nerve blocks of the airway as well as crycothyroidotomy for emergency airway procedures.

Identification of the Cricothyroid Membrane

Visualization and external palpation of the cricothyroid (CT) membrane may be difficult at times. This may impair our ability to perform a translaryngeal block for awake fiberoptic or lower the success rate of cricothyrotomy.  Ultrasound can help in this regard as it greatly improves identification of the bony structures and the depth necessary to reach the airway. Lets identify this membrane on the planes described above.

​

String of Pearls Technique

This is the most well published and proven technique compared to palpation alone. This technique can also be used for optimal tracheostomy tube placement since it can accurately identify trachea rings.



Start by placing the probe at the base of the neck in a transverse orientation to get the short axis of the trachea in view which is visualized as a horseshoe shaped dark structure. Make sure that the midline of the probe corresponds to the midline of the trachea. Next, rotate the probe 90 degrees so that the indicator is pointing towards the head. A number of dark hypoechoic structures will appear corresponding to the anterior part of the tracheal rings that correspond to the 'pearls' of the String of Pearls technique. From here translate the probe upwards to the head. Take a look at the images below for reference . The cricoid is initially seen as a larger elongated hypoechoic 'pearl'. As the probe moves up the inferior portion of the thyroid cartilage is seen. The cricothyroid membrane can thus be located and can be marked.

02 US SOP gifff.gif

String of Pearls technique. Probe movements and corresponding ultrasound images. An outline of the bony structures is overlayered on the maneuver aid in understanding the corresponding US image. The maneuver consists on rotating the probe once the trachea is identified and moving the probe upwards until a string of pearls is seen. The probe is moved 90 degrees towards the head once the trachea's midlines is in line with that of the probe. The string of pearls is seen before we can observe the cricoid and then the thyroid cartilage. The hyperechoic line that joins all the structures corresponds to the air-muscosal interface. On blue, the thyroid, cricoid and first tracheal ring. See text above for more information.

Thyroid-Airline-Cricoid-Airline or TACA technique

This technique is recommended when the SOP technique is not feasible due to limited neck mobility or very short neck. This technique can also be used in conjunction to the SOP technique for proper localization of the cricothyroid membrane.

​

Start at the level where you identified the thyroid cartilage and place the ultrasound probe over this structure. This cartilage appears a hyperechoic triangular structure. The transducer is then moved caudally with the cricothyroid membrane appearing as a hyperechoic white line. As the transducer is moved down further a C shaped structure corresponds to the cricoid. The transducer can then be moved back up the neck for marking of the cricothyroid membrane.

02- 2 TACA labels.gif

TACA technique. On the left the ultrasound probe movements with an overlay of the relevant anatomical structures. The movements on this maneuver have been exaggerated for demonstration purposes. The probe is moved down once the thyroid cartilage is identified (Start on the US image) as a triangular structure. It is then moved down. The cricothyroid membrane is encountered next followed by the C shaped cricoid. The probe is then moved back up to the CT membrane.

Lets have a closer look at the TACA technique based on still images to clarify the above concepts.

Below you will see an overlay of the bony structures on top of the ultrasound images as the movement of the probe slides down from the thyroid cartilage (position 1), to the cricothyroid membrane (position 2), then to cricoid (position 3) and finally back to position 2.

Section thyroid.gif

1. THYROID

Section cricoid.gif

3. CRICOID

Section ct membrane.gif

2. AIR

Section ct membrane.gif

2. AIR

B mode of the TACA protocol. Start at position 1 with the thyroid, followed by the cricothyroid membrane, then cricoid at position 3 and back to position 2 at the cricothyroid membrane.

SOP|TACA

US Procedures of the Airway

From airway blocks to tracheostomies, lets review what US can be used for.

1.  Translaryngeal block with US

Before we go any further, make sure you have considered analgesia as part of your anesthetic plan when performing an awake fiberoptic.The aim here is to allow the procedure while at the same time provide optimal intubating conditions.



Now that we have identified the location of the CT membrane we can either mark its location or use of real time sonography to perform a translaryngeal block. The ultrasound probe starts at a midline long axis view or sagital view as in the SOP technique and then it is tilted from the midline while keeping the cricoid cartilage in view. The needle entry point should then be cranial to the cricoid cartilage. The needle is advanced using negative aspiration and the tracheal location of the tip of the needle is confirmed by the presence of  air in the syringe.

Image by I8r8oosh

Before we go any further, make sure you have considered analgesia as part of your anesthetic plan when performing an awake fiberoptic.  This ideal sedation should include The aim here is to allow the procedure while at the same time provide optimal intubating conditions.



Now that we have identified the location of the CT membrane we can either mark its location or use of real time sonography to perform a translaryngeal block. The ultrasound probe starts at a midline long axis view or sagital view as in the SOP technique and then it is tilted from the midline while keeping the cricoid cartilage in view. The needle entry point should then be cranial to the cricoid cartilage. The needle is advanced using negative aspiration and the tracheal location of the tip of the needle is confirmed by the presence of  air in the syringe.

1. Translaryngeal

2. Percutaneous Tracheostomy

The trachea and paratracheal soft tissues of the neck can be readily examined with high frequency US probes of due to their superficial position. This implies that the anterior tracheal wall, thyroid and cricoid cartilages, tracheal rings, and pre-tracheal tissue may all be well visualized. Ultrasound can thus assist in tracheostomy placement in selecting the optimal intercartilaginous space for tracheostomy. US can predict the proper tracheostomy tube size for exchange in children by assessing the internal and external transverse tracheal diameter and the depth of the trachea.



10 SOP from base gif.gif
10 SOP STILL.gif

AM

T 2

T 3

T 1

C

Determining the location of the tracheostomy site based on US findings. The US probe is moved on the long axis of the neck (longitudinally) until encountering the cricoid. The tracheal rings can then be numbered down from the cricoid down to determine optimal surgical location. C, cricoid; T1, first tracheal ring; T2, second tracheal ring; T3, third tracheal ring; AM, air-mucosal interface.

Perc trach

3. Superior laryngeal block with US

Like the translaryngeal block, consider analgesia as part of your anesthetic plan when performing an awake fiberoptic.  The aim here is to allow the procedure while at the same time provide optimal intubating conditions.



It may be challenging to identify bony landmarks in order to perform a block on the internal branch of the superior laryngeal nerve.  This sensory nerve will be located caudal to the greater cornu of the hyoid bone. In order to do this we must first identify the hyoid bone. This is done by moving the ultrasound probe in a cephalad direction from a sagittal (median long axis) view (see 1 below).  Once the probe is identified then the probe is rotated to a transverse view and moved laterally. This movement will identify the superior and lateral aspect of the thyrohyoid membrane which will be the entry point of the internal branch of the superior laryngeal nerve. The nerve block (1-2ml of local anesthetic) can then proceed with either an inplane or out of plane technique by aiming at the space directly inferior to the greater cornu of the hypid bone.  Lets first start with the probe movements followed by the ultrasound clips you should be seeing.

First Step: Visualize the hyoid bone on short axis

Image by I8r8oosh

 1

Probe movements to optimize superior laryngeal nerve block. The probe is first moved upwards from a sagittal plane until the hyoid bone comes into view. Notice the corresponding ultrasound image to the right.

Sup laryn block

Second Movement: Visualize the greater corny of the hyoid bone

Image by I8r8oosh

 2

SLN

H

Probe movements to optimize superior laryngeal nerve block. The probe has been rotated orthogonal and moved laterally to visualize the location of the greater cornu of the hyoid bone.  We can identify the superior laryngeal artery and nerve (SNL) lateral to the greater cornu of the hyoid bone (H). The SNL here will divide into internal and external branch and our goal is to block the internal branch before penetrating the thyrohyoid membrane.

Third step: The superior laryngeal block.

The nerve block (1-2ml of local anesthetic) can then proceed with either an inplane or out of plane technique by aiming at the space directly inferior to the greater cornu of the hypid bone. Here we show an out of plane technique.

Image by I8r8oosh
Image by I8r8oosh

The probe starts sagittal and midline by visualizing both the hyoid (H) and thyroid cartilages (T). The thyrohyoid membrane (TH) runs between these two structures. We then translate the probe laterally while keeping the bony structures in visual line of sight. The object here is to place local anesthesia close to the greater cornu. Syringe image depicts the target of local for this block.

4. Tracheal placement and location of endotracheal tube

Ultrasound of the airway can also be used to confirm proper positioning of the endotracheal tube as an adjunction to standards of practice (visualization between vocal cords, end-tidal CO2, and endoscopic visualization of tracheal rings through the endotracheal tube). Here the goal is to evaluate proper tube placement by indirectly ruling out an esophageal intubation.

Endotracheal tube not in the esophagus.

We start with the ultrasound probe placed in a transverse position at the base of the anterior neck. The tracheal rings will be identified as C-shaped hypoechoic structures with deeper hyperechoic structures corresponding to the tissue-air border. The esophagus will be seen on the side of the trachea as an oval structure with an hyperechoic wall and hypoechoic center. The probe can be placed while the placing the endotracheal tube. An esophageal intubation will create an adjacent hyperechoic structure posterolateral to the trachea, also known as the 'double tract sign'. Ultrasound may not be able to identify esophageal intubation in the case of an esophagus lying directly posterior to the trachea. The trachea in this case will cause acoustic shadowing of the esophagus and thus will not be seen. If the esophagus cannot be observed on initial evaluation moving the probe towards the left will help reduced the acoustic shadow caused by the thyroid cartilage.

E

E

Identification of the esophagus. To help identify the esophagus, movement of the probe to the side of the neck (either side) may be necessary as illustrated on the video to the left and the corresponding image on the middle of the screen. E for esophagus.  The right most image is taken on the side of the neck on the transverse view.

 ETT in esophagus: Double barrel sign

Confirmation of the endotracheal tube (ETT) in the esophagus can be done with the double barrel sign. When interrogating the trachea with ultrasound there should only be one air-mucosa interface. The presence of a second air interface of a second air-mucosal interface implies that the ETT is actually in the esophagus.

E

20 Second double barrel.gif

E

20 Double barrel sign.gif

DB

Intubation of the esophagus. Left: an empty esophagus that expands as an ETT is advanced and appears as a double barrel sign. On the right, the double barrel (DB) sign creating a second air-mucosa interface which implies the ETT is in the esophagus. The ETT has already been placed in this clip.

4.ETT location

ETT in the trachea

The following are US signs can also be used to confirm the presence of the ETT in the trachea as well as its location within the trachea. These include the 'snowstorm' and the the 'bullet' sign. The snowstorm artifact is created when the endotracheal tube advances into the trachea. The bullet sign is a single air-mucosal interface with increased posterior shadowing and increased diameter of the trachea. The air in the ETT balloon causes displacement of the walls of the trachea creating this artifact.

Bullet sign as seen in B mode ultrasound. On the left, the ETT cuff is inflated after the tube has been placed. On the right, the same clip but with two features. A cross section of a hollow ETT with its cuff being inflated appears in the image. This is then followed by the 'bullet' image overlay. The displacement cause by the ETT cuff creates a wider bony surface and thus casting a greater acoustic shadow. Images taken at the suprasternal notch.

Location of the ETT in the trachea

We can use the long axis or longitudinal view of the trachea to determine the location of the endotracheal cuff to evaluate its proper position. The optimal location of an endotracheal tube tip is between 5 +/- 2cm from the carina on neutral position. The cuff should then lie below the cricoid and above the lowest suprasternal tracheal ring that can be visualized. Bear in mind that due to different size tubes and manufacturers it would be prudent to check for bilateral lung sliding to confirm both lungs are ventilating. On the following clips we can identify the crycoid, the tracheal rings and its relation to the endotracheal cuff.

CT

Inflated ETT cuff in long axis. Long axis view or longitudinal view of the trachea as the cuff is inflated. Both clips are display the same information. Right clip has an overlay of an ETT as the cuff is being inflating causing an anterior displacement of the bony structures of the trachea and in this case the cricoid is displaced and thus the proceduralist should advance the ETT. CT for cricothyroid membrane.

5.ETT size

5. Tracheal US and ETT size

Optimal ETT Size

Ultrasound is a reliable tool to assess the infraglottic diameter of the upper airway.  Ultrasound derived formulas to estimate the size of the endotracheal tube is superior to age and height-based formulas in estimating endotracheal tube size.

The correct size of tracheal tube was highly correlated with the subglottic diameter. This diameter is taken just below the cricoid cartilage. Linear models estimate endotracheal tube size with the following formula (keep in mind that while the internal diameter of a tube does not vary across manufacturers, the outer tube diameter does) :



01-2 neck sx going down gif labels.gif

When using US derived measurements to estimate the size of the ETT:

​

Neonate and infants:

​

              ETT OD (mm) = 0.55 × SD on ultrasound (mm) +  1.16.



In children older than 12 months:

​

               ETT OD (mm) = 0.01 × age (months) + 0.02 × height (cm) + 3.3.

Measurements of the airway at the level of the cricoid as its smallest diameter. Dotted line represents the measurements taken at the cricoid cartilage on its largest dimension representing the smallest diameter. T thyroid and C, cricoid.

Estimating the size of Double Lumen Tubes

Double lumen tubes (DLTs) are frequently to manage the airway in cases requiring one-lung ventilation or in critically ill patients but adequate sizing is often difficult. Inserting an inappropriate size can lead to significant clinical problems including unable to completely isolate the lung, severe injury to the airway, and the need to exchange the tube for a different size.



There are two main approaches for the correct selection of DLT size. First, there are reference tables based on height and gender. The second method incorporates radiographical information including tracheal width and and size of the left main-stem bronchus. Ultrasound (US) offers an alternative. There is a direct correlation between tracheal width and left main-stem bronchial width as measured by CT. Thus if left bronchial width cannot be measured directly, the tracheal width can be used to predict bronchial width. Tracheal width measured by US as a guide to determine DLT size does so in approximately 75% of patients which is comparable to that obtained by chest radiograph as a guide to estimate DLT. This measurement is the outer diameter of the trachea just above the sternoclavicular joint. The following table can be used as a guide to estimate left sided DLT size.

trachea still.gif

Guideline for determining proper left sided DLT (LDLT) based on tracheal width (TW) measured by US.

US of the trachea just above the suprasternal notch. Dimensions here reflect the transverse outer diameter (OD) of trachea or tracheal width.

LDLT size, left main bronchus diameter (LBM), and TW as measured by CT and TW by US. F, French. Modified from Sustic A and all.

An important relevant problem here lies on the fact that there are considerable dimensional differences among similarly sized DLTs from different manufacturers.
